CPU300MHz Mips Single core
Chip modelRTL9601D-VA3
Memory8MB SIP NOR Flash/32MB DDR2 SOC
Bob DriverGN25L95
XPON Protocol SpecificationComply ITU-T G.984 GPON standard:G.984.1 general characteristicsG.984.2 physical Media Dependent (PMD) layer specificationsG.984.3 transmission convergence layer specificationsG.984.4 ONT management and control interface specificationSupport DS/US transmission rate to 2.488 Gbps/1.244 GbpsWavelength: 1490 nm downstream & 1310 nm upstreamComply with class B+ type PMDPhysical distance reach to 20 kmSupport Dynamic Bandwidth Allocation (DBA)GPON Encapsulation Method (GEM) supports Ethernet packetSupports GEM header removal/insertion and data extraction/segmentation (GEM SAR)Configurable AES DS and FEC DS/USSupport up to 8 T-CONs each with priority queues (US)
Network Protocol Specifications802.3 10/100/1000 Base T Ethernet ANSI/IEEE 802.3 NWay auto-negotiation 802.1Q VLAN tagging/un-taggingSupport flexible traffic classificationSupport VLAN stakingSupport VLAN Intelligent Bridging and Cross Connect mode
